3rd Gen Intel Xeon Scalable Processors ASUS Servers

ASUS servers powered by 3rd Gen Intel Xeon Scalable processors help customers cut down time to solution for a wide variety of applications, add improved security features and enable all workloads to be run in the cloud, on-premises or a private cloud.

ASUS Servers featuring 3rd Gen Intel Xeon Scalable processors deliver significantly enhanced performance and efficiency. 3rd Gen Intel Xeon Scalable processors are optimised for cloud, HPC, security, network, enterprise and IoT workloads and feature up to 40 powerful cores.


ASUS RS700-E10-RS4U (90SF0153-M002H0)

1U dual-socket server powered by 3rd Gen Intel Xeon Scalable processors that supports up to 32 DIMMs, one dual-slot GPU, 4 NVMe, four PCIe slots, one OCP 3.0, dual M.2 and ASUS ASMB10-iKVM.

U Size:
1U
Drives:
SATA Support , SAS Support, NVME Support
HDD Size:
3.5" Drives
Drive Bays:
Hot-Swap Drives
Chassis Features:
Redundant Power
Maximum RAM:
4 TB
CPU Sockets:
Dual Processor
Processor Family:
3rd Gen Intel Xeon Scalable Processors
Expansion Slots:
4x PCI-E
Konfigurieren Ab: €3,472
Konfigurieren
ASUS RS720-E10-RS12 (90SF00Z3-M00920)

2U dual-socket server powered by 3rd Gen Intel Xeon Scalable processors that supports up to 32 DIMMs, four dual-slot GPUs, eight NVMe, nine PCIe 4.0 slots, OCP 3.0, dual M.2 and ASUS ASMB10-iKVM.

U Size:
2U
Drives:
SATA Support , SAS Support, NVME Support
HDD Size:
2.5" Drives
Drive Bays:
Hot-Swap Drives
Maximum RAM:
4 TB
CPU Sockets:
Dual Processor
Processor Family:
3rd Gen Intel Xeon Scalable Processors
Expansion Slots:
6x PCIe
Konfigurieren Ab: €4,317
Konfigurieren
ASUS RS720-E10-RS12E (90SF00Z8-M00360)

2U dual-socket server powered 3rd Gen Intel Xeon Scalable processors that supports up to 32 DIMMs, four dual-slot GPUs, eight NVMe, nine PCIe 4.0 slots.

U Size:
2U
Drives:
SATA Support , SAS Support, NVME Support
HDD Size:
2.5" Drives
Drive Bays:
Hot-Swap Drives
Chassis Features:
Redundant Power
Maximum RAM:
4 TB
CPU Sockets:
Dual Processor
Processor Family:
3rd Gen Intel Xeon Scalable Processors
Konfigurieren Ab: €4,317
Konfigurieren
ASUS ESC4000-E10 (90SF01B3-M00500)

2U dual-socket GPU server powered 3rd Gen Intel Xeon Scalable processors that supports up to 16 DIMM, four dual-slot GPU, 4 M.2, eight NVMe (by SKU), total eleven PCIe 4.0 slots.

U Size:
2U
Drives:
SATA Support , SAS Support, NVME Support
HDD Size:
2.5" Drives
Drive Bays:
Hot-Swap Drives
Chassis Features:
Redundant Power
Maximum RAM:
2 TB
CPU Sockets:
Dual Processor
Processor Family:
3rd Gen Intel Xeon Scalable Processors
Konfigurieren Ab: €5,297
Konfigurieren
ASUS ESC4000-E10S (90SF01B3-M004P0)

2U dual-socket GPU server powered 3rd Gen Intel Xeon Scalable processors that supports up to 16 DIMM, four dual-slot GPU, 4 M.2, 4x NVMe (by SKU), Up to 11x PCIe 4.0 slots.

U Size:
2U
Drives:
SATA Support , SAS Support, NVME Support
Integrated Features:
Dual Port Intel I350-AM2 Gigabit LAN controller
HDD Size:
2.5" Drives
Drive Bays:
Hot-Swap Drives
Chassis Features:
Redundant Power
Maximum RAM:
2 TB
CPU Sockets:
Dual Processor
Processor Family:
3rd Gen Intel Xeon Scalable Processors
Expansion Slots:
6x PCIe
Konfigurieren Ab: €5,326
Konfigurieren
ASUS RS720-E10-RS24U (90SF00Z3-M000T0)

2U dual-socket server powered by 3rd Gen Intel Xeon Scalable processors that supports up to 32 DIMMs, 24 NVMe, nine PCIe 4.0 slots, OCP 3.0, dual M.2 and ASUS ASMB10-iKVM

U Size:
2U
Drives:
SATA Support , SAS Support, NVME Support
HDD Size:
2.5" Drives
Drive Bays:
Hot-Swap Drives
Maximum RAM:
4 TB
CPU Sockets:
Dual Processor
Processor Family:
3rd Gen Intel Xeon Scalable Processors
Konfigurieren Ab: €5,593
Konfigurieren
ASUS RS720Q-E10-RS8U (90SF0141-M000C0)

2U4N server powered by 3rd Gen Intel® Xeon Scalable processors, with each node supporting up to 16 DIMM, one PCIe® 4.0 slot, one OCP 3.0 and two M.2, and a total of eight NVMe/SAS/SATA drives.

U Size:
2U
Drives:
SATA Support , SAS Support, NVME Support
HDD Size:
2.5" Drives
Drive Bays:
Hot-Swap Drives
Chassis Features:
Redundant Power
Maximum RAM:
2 TB
CPU Sockets:
Dual Processor
Processor Family:
3rd Gen Intel Xeon Scalable Processors
Expansion Slots:
4x PCI-E
Konfigurieren Ab: €10,063
Konfigurieren

Call a Broadberry Storage & Server Specialist Now: +49 89 1208 5600

Wir melden uns gern zurück

The ASUS series servers in this range are powered by the ultra-fast 3rd Gen Intel Xeon Scalable processor family. Select from servers that integrate dual-socket, single socket and multi-node solutions for specific workloads in HPC, AI, databases and hypervisors to get the most out of the new platform, which includes Intel Optane persistent memory 200 series, PCIe 4.0 and Intel Ethernet.

3rd Gen Intel Xeon Scalable processors feature up to 40 cores and a variety of frequency and power supports. 3rd Gen Intel Xeon Scalable processors provide blazing fast performance that is up to 40% faster than their prior gen counterparts. This platform possesses a wide range of built-in security features and provides outstanding security performance including data integrity, encryption and authentication.


Worlds First Real-Time RAM-Assessment Server

ASUS collaborated with firmware partners to enhance system-memory usage efficiency and management based on the 3rd Gen Intel Xeon Scalable platform. To minimise memory-failure rates and optimise migration whilst running critical workloads on VMs, Intel Memory Failure Prediction (MFP) technology is built in to ASUS ASMB10-iKVM. This lessens the need for replacement DDR4 DIMMs, which can lead to cost benefits.


The newest server-management solution from ASUS, the ASUS ASMB10-iKVM is built on the ASPEED 2600 chipset running on the latest AMI MegaRAC SP-X. The systems delivers a variety of interfaces to allow out-of-band server mangement through WebGUI, Intelligent Platform Management Interface (IPMI) and Redfish API.

ASMB10-iKVM is an agentless management module for securely, efficiently and effectively controlling ASUS servers. When an ASUS server is connected to power and networking, ASMB10-iKVM allows that system to be monitored and fully managed either on-premises or over a network remotely.


3rd Gen Intel Xeon Scalable Processors Are...
  • Optimised for cloud, HPC, enterprise, security, network and IoT workloads with 8 to 40 powerful cores and a multitude of frequency and power levels.
  • Infused with Intel Crypto Acceleration, enhancing the performance of encryption intensive workloads including SSL web serving, 5G infrastructure and VPN/firewalls whilst reducing the performance impact of pervasive encryption.
  • The only data centre CPU featuring built-in AI acceleration, end-to-end data science tools and an ecosystem of smart solutions.
  • Designed and built for the demands of cloud workloads and to support a variety of XaaS environments.
  • Powered by Intel 5GX, which safeguards data and application code from the edge to the data centre and multi-tenant public cloud.

3rd Gen Xeon Scalable Platinum Processors
  • Up to 40 cores per Intel Xeon Platinum processor.
  • Up to 8 memory channels at up to 3200 MT/s
  • Features built-in AI acceleration (Intel DL Boost) with int8 (VNNI) and bfloat165 quantisation for accelerated AI inference and training performance.
  • Features Intel SGX, the most deployed trusted execution environment, with up to 512GB enclave per processor.
3rd Gen Xeon Scalable Gold Processors
  • Up to 32 cores per Intel Xeon Gold processor
  • Up to 8 memory channels at up to 3200 MT/s.
  • Featuring Intel SGX, the most deployed trusted execution environment, with up to 64GB enclaves per processor.
3rd Gen Xeon Scalable Silver Processors
  • Up to 20 cores per Intel Xeon Silver processor.
  • Up to 8 memory channels at up to 2667 MT/s.
  • Featuring Intel SGX, the most deployed trusted execution environment, with up to 8GB enclave per processor.

3rd Gen Xeon Scalable Processor Specifications

Maximum Core Count Supported Up to 40
Base Frequency Supported Up to 3.1 GHz
Maximum Single-Core Intel Turbo Boost Technology 2.0 Frequency Supported Up to 4.3 GHz
Processor Cache Memory Support Up to 38.5 MB of L3 Cache (1.375 MB/core)
Intel Ultra Path Interconnect (Intel UPI) Six Intel UPI supported per processor (Up to 10.4 GT/s)
Processor Performance Support Intel Turbo Boost 2.0 Technology, Intel Hyper-Threading Technology (Intel HT), Intel Speed Shift Technology, Enhanced Intel SpeedStep Technology
Intel Speed Select Technology (Intel SST) Intel SST Core Power (SST-CP) and Intel SST Turbo Frequency (SST-TF) features are supported on select processors
Intel Deep Learning Boost VNNI and bfloat16 supported
Intel Advanced Vector Extension 512 (Intel AVX-512) Support Intel AVX-512 with up to 2 FMA support
Number of Processor Sockets Supported 4 or 8 sockets
Thermal Design Point (TDP) Supporting a range from 150W to 260W depending on customer needs and implementation
Socket Type Socket P+ (4189 pins)
System Memory Support 6 channels, Up to DDR4 3200 MT/s (1 DPC) with ECC support
12 DIMMs/socket, Support for 16Gb density DIMMs
Intel Optane Persistent Memory Support Intel Optane Persistent memory 200 series supported on 4-socket systems only
Maximum DRAM System Memory Supported Up to 4.5 TB per socket
Supported Chipsets Intel C620A series chipsets, available with integrated Intel QuickAssist Technology
PCH I/O PCI Express* 3 - Up to 20 lanes (8 GT/s)
USB* 3.0 - Up to 10 ports
SATA* 3.0 - Up to 14 ports
DMI - Up to 4 lanes, Gen 3
Platform Manageability Intel Server Platform Services (Intel SPS) and Intel Resource Director Technology (Intel RDT)
Storage Manageability Intel Volume Management Device (Intel VMD)
